Washer Disinfector

Washer Disinfector (Lab Automatic Glassware Washer)

Model

BK-LW100P BK-LW200Pro BK-LW300P BK-LW360

Brand

BIOBASE

Get Price

Product Description

Features:

1. 7.1 inch color LCD touch screen, easy to operate.

2. Provides 12 custom changeable program groups, cleaning programs can be combined at will.

3. With automatic fault diagnosis program.

4. Three-level password permission management for easy supervision.

5. The exterior is made of 304 brushed stainless steel, resistant to corrosion.

6. Standard HEPA filter with filtration efficiency >99.99%.
Lab Automatic Glassware Washer

Technical Parameters:

Model

BK-LW100P

BK-LW200Pro

BK-LW300P

BK-LW360

Cleaning

Capacity(L)

130

206

308

380

Washer Load Level

2

4

4

6

Water Wash Power(KW)

0.75

0.75

1.5

1.5

Water Heater Power(KW)

2

4

6

6

MAX. Power(KW)

4

5

7.5

7.5

Water Consumption/Step(L)

18~24L

Tank Internal Temperature(℃)

0~95

Water Supply Pressure(Mpa)

＞0.2

Peristaltic Pump for Cleaning Agent

2

Cleaning Agent Level Sensor

YES

Washing Pump

Sweden 360L/min

Cleaning Racks

Optional

Drying

Drying Function

YES

Steam Condenser

YES

Dry Power(KW)

2.4

4

6

6

Control System and Traceability

Control System

7″ color LCD touch screen display, MCU

7″ color LCD touch screen display, PLC

Cleaning Program

7 pre-set programs+12 MCU free programming

7 pre-set programs+6 PLC free programming

Password Protection

3 levels password

Safety Emergency Button

YES

USB Port

Optional

Integrated Printer

Optional

Online Monitor Performance of Washing

NO

Optional

Dimensions&Weight

Chamber Dimension(W*D*H, mm)

560*530*633

552*565*807

690*670*966

680*632*1260

Exterior Dimension(W*D*H, mm)

908*716*800

907*715*998

701*845*1655

701*845*1785

Package Dimension(W*D*H, mm)

850*1000*1200

860*1000*1250

920*1060*1900

1080*880*1900

Net Weight(Host only, kg)

160

170

250

330

Gross Weight(Host with rack, kg)

180

200

280

320

Others

Door

304 stainless steel

Safety Door Lock

YES

Built-in RO Water Pump

YES

Noise(dB)

<65

Voltage(V/Hz)

Standard: 220V, 50Hz:

Optional: 110V, 50/60Hz; 220V, 60Hz(External transformer)

Standard: 220V, 50Hz;

Optional: 110V, 50/60Hz；220V, 60Hz(External transformer)

Standard: 380V, 50Hz；Optional: 110V, 50/60Hz; 220V, 50/60Hz; 380V, 60Hz(External transformer)

Standard: 380V, 50Hz: Optional: 110V, 50/60Hz; 220V, 50/60Hz; 380V, 60Hz(External transformer)
