PCR Cabinet PCR800 PC1000 PCR1200 PCR1300 PCR1500

Laminar Flow Cabinet

Model	PCR800, PC1000, PCR1200, PCR1300, PCR1500
Brand	BIOBASE

Features:
1. LCD display(LED display for PCR1000).

2. UV sterilization system.

3. HEPA filter efficiency 99.999% at 0.3μm.

4. With memory function in case of power-failure.

4. Interlock function: UV lamp only can be switched on when the front window is closed, ensuring operator safety.

5. UV timer(0~90 minutes): When the setting time expires, the UV lamp automatically switches off in preparation for the next experiment.

PCR800

Technical Parameters:

Model	PCR-800	PCR-1000	PCR-1200	PCR-1300	PCR-1500
External Size(WDH)	8007001770mm	10007051770mm	12007001770mm	13007001770mm	15007001770mm
Internal Size(WDH)	700595550mm	900595560mm	1100595550mm	1200595550mm	1400595550mm
Work Surface Height	750mm
Material	Main Body: Cold-rolled steel with anti-bacteria powder coating
	Work Table: 304 stainless steel
Front&Side Windows	5mm toughened glass, anti-UV
	Motorized	Manual	Motorized
Max Opening	300mm	320mm	300mm
Pre-filter	Polyester fiber, washable
HEPA Filter	99.995% efficiency at 0.3μm
Airflow Velocity	0.3~0.5m/s, speed adjustable
Noise	≤65dB
UV Lamp	20W*1	20W*2	30W*1	30W*1	40W*1
	Emission of 253.7 nanometers, with UV timer
LED Lamp	8W*2		12W*2
Illumination	≥350lx
Shelf with IV Bar	Stainless steel, 50215050mm(WDH)
Caster	Universal caster with leveling feet
Consumption	400W	300W	600W
Waterproof Socket	Two, total load≤500W
Power Supply	AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Standard Accessory	UV lamp, Fluorescent lamp, Base stand, Waterproof socket*2, Shelf with IV bar
Optional Accessory	Electric height adjustable base stand
Gross Weight	168kg	178kg	220kg	231kg	250kg
Package Size(WDH)	960940 1450mm	1150930 1450mm	1350930 1450mm	1450930 1450mm	1650930 1450mm
