Sterilizer

Bed Unit Ozone Sterilizer

Model

ZY-Y-CY5G

Brand

BIOBASE

Product Description

Features:

1. 7-inch color touch screen, microcomputer control, long service life, low light loss and system energy consumption and convenient man-machine interaction.

2. With consumable life alarm function.

3. Manual/automatic mode is optional, free to set disinfection time.

4. Clock display function to accumulate disinfection time, real-time temperature monitoring.

5. Special lockers are provided before and after the machine to facilitate users to store items such as ozone output tubes.

6. With ozonolysis device, the treated gas can be directly discharged into the air, healthy and pollution-free.

7. Equipped with high-power air compressor, so that ozone can completely enter the interior of cotton wool and other items for disinfection.

8. Stainless steel ceramic ozonator, high purity ozone, large amount of production, long service life.

Technical Parameters:

Model

ZY-Y-CY5G

Disinfection Method

Ozone

Ozone Generation

5000mg/h

Max Ozone Concentration

≥1700mg/m3

Ozone Filling Time

0~99min(Customizable)

Disinfection Time

0~99min(Customizable)

Pump-out Time

0~99min(Customizable)

Parsing Time

0~99min(Customizable)

Noise

45~50dB(A)

Special Function

Single and twin bed mode, temperature detection, analytical agent change prompt, selection of disinfection cycles, time can be set and scheduled disinfection is available

Consumption

410VA

Power Supply

Standard: AC220V, 50/60Hz

Optional: 110V, 50/60Hz

External Size(W*D*H)mm

320*380*830

Package Size(W*D*H)mm

400*460*967

Net Weight(kg)

31

Gross Weight(kg)

35.5
