-86°C Freezer 588L 728L 838L

-86°C Freezer

Model	BDF-86V588 BDF-86V838 BDF-86V728
Brand	BIOBASE

Technical Parameters:

Model		BDF-86V588	BDF-86V728	BDF-86V838
External Size(WDH)mm		88010802000	1260*890″2010	117510751990
Internal Size(WDH)mm		6067381310	9635581350	8947181310
Capacity		588L	728L	838L
Type		Vertical
Temp. Range		-40℃~-86℃
Temp. Accuracy		0.1℃
Control System		Microprocessor control, LCD touch screen		Microprocessor control, LED digital display
Audible and Visual Alarm		High and low temperature, Sensor failure, Door ajar, Power failure, Voltage abnormal, Ambient temperature abnormal, Low voltage, Filter blocking
Refrigeration Type		Direct refrigeration
Refrigerant		R290 and R170
Compressor		2 sets
Condenser&Evaporator		Made of copper
Construction	Structure	150mm ultra-thick foam layer	100mm ultra-thick foam layer	150mm ultra-thick foam layer
	Internal Material	SS 304
	External Material	Sprayed steel plate
Door		Lockable door
Caster		4 casters
Chamber with Inner Door		2
Shelf		3pcs
Temp.Test Port		1, φ25mm	1, φ25mm	1, φ25mm
Consumption		815W/760VA	935W/800VA	1700W/1400VA
Power Supply		AC110V/220V±10%, 50/60Hz
Standard Accessory		72 hours battery backup for power failure alarm, USB port
Optional Accessory		/	/	Printer
Max.Optional Storage Racks		16LD55	24LD54	18LD75
Max. Optional Boxes		400	480	630
Package Size(WDH)mm		97511402200	13209702190	127011002185
Gross Weight(kg)		368	401.5	430
