-86°C Freezer

Model	BDF-86V28 BDF-86V58 BDF-86V50 BDF-86V108
Brand	BIOBASE

Technical Parameters:

Model		BDF-86V28	BDF-86V50	BDF-86V58	BDF-86V108
External Size(WDH)mm		5055201165	6607151165	6357571212	7007301260
Internal Size(WDH)mm		266281400	360456395	330453410	460460510
Capacity		28L	50L	58L	108L
Type		Vertical
Temp. Range		-40℃~-86℃
Temp.Accuracy		0.1℃
Control System		Microprocessor control, 7-inch LCD touch screen
Alarm		High and low temperature alarm, sensor failure alarm	High and low temperature alarm, power fault alarm, thermostat fault alarm	High and low temperature alarm, sensor failure alarm, thermostat failure alarm power failure alarm, door open alarm, ambient temperature alarm, condenser failure alarm, filter inspection alarm, abnormal voltage alarm, low battery alarm	High and low temperature alarm, sensor failure alarm

Alarm Method		Sound beeps and lights flash
Refrigeration Type		Direct refrigeration
Refrigerant		R404a, R23	R600a 85g, R290 15g, R1150 27g, R14 20g	R290, R170	R404a, R23
Compressor		1pc
Construction	Foam Layer Thickness	100mm	130mm	150mm	120mm
	Internal Material	304 stainless steel
	Extemal Material	Sprayed steel plate
Chamber with Inner Door		1	1	1	2
Shelf		1	1	1	2
Temp. Test Port		1pc, dia. 18mm	1pc, dia. 30mm	1pc, dia. 25mm	1pc, dia. 18mm
Consumption		390W/1170VA	540W/550VA	442W/400VA	520W/1560VA
Power Supply		AC110V/220V±10%, 50/60Hz	AC110~220V, 50/60Hz	AC110V/220V±10%, 50/60Hz	AC110V/220V±10%, 50/60Hz
Standard Accessory		/	/	USB port	/
Optional Accessory		USB port	USB port	Printer	USB port
Package Size(WDH)mm		5806001325	7658251350	7308451400	7858001430
Gross Weight(kg)		85	134	155	133
