| Model |
BK-6310 |
| Throughput |
60 tests/hour |
| Assay Items |
5 parts, 29 parameters, 3 histograms, 3D scattergram |
| Principle |
Tri-angle laser scatter, Flow cytometry method, 3D scattergram analysis, Impedance method for RBC and PLT counting, Cyanide-free method for HGB test |
| Test Mode |
CBC mode, CBC+DIFF mode venous whole blood, Capillary whole blood and prediluted |
| Parameters |
WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PCT, PDW, P-LCR, P-LCC, NEU%, LYM%, MON%, EOS%, BAS%, NEU#, LYM#, MON#, EOS#, BAS#, ALY%, ALY#, IG%, IG# |
| Sample Volume |
CBC+DIFF mode: ≤20μl, CBC mode: ≤10μl |
| Storage |
10,000 results including histogram, scattergram and patient information |
| Interface |
4 USB ports, 1 LAN port Bi-direction LIS, support HL7 protocol, Internal RFID reader |
| Power Supply |
AC220V±10%, 50/60Hz; 110V±10%, 60Hz; 400VA |
| Package Size (W*D*H) |
575*490*690mm |
| Gross Weight |
46kg |
| Reagent Package Size |
330*330*330mm, 400*290*240mm, 400*290*240mm |
| Reagent Gross Weight |
22kg, 2kg, 1kg |
