-20/25℃ Freezer(Economic Type) – Mariken Weida Corporation

-25°C Freezer

Model	BDF-20V40 BDF-25V230 BDF-25V300
Brand	BIOBASE

Technical Parameters:

Model		BDF-20V40	BDF-25V230	BDF-25V300
Capacity		40L	230L	300L
Temp. Range		-10~-20℃	-10~-25℃
Temp. Accuracy		1℃
Temp. Uniformity		≤3℃
Temp. Stability		≤3℃
Control System		Microprocessor control
Display		LED
Alarm		High and low temperature alarm, thermostat fault alarm, door switch alarm
Refrigeration Type		Direct-cooling
Refrigerant		R600a/40g	R600a/64g	R600a/80g
Compressor		International famous brand compressor/1
Condenser&Evaporator		Bundy tube, side plate type; aluminum tube, wound tube type	Bundy tube, side plate type; wire, tube type
Defrost		Manual defrost	Automatic/Manual defrost
Construction		Polyurethane cyclopentane foam
Material	Internal Material	HIPS
	External Material	Precoated steel plate
Door		1/Cyclopentane monolithic foam door
Consumption		90W	110W	120W
Power Supply		AC220V, 50Hz(Standard); 220V, 60Hz, 110V, 60Hz(Optional, external transformer)
Casters		No
Adjustable Shelves/Drawer		1	6	8
Standard Accessory		Test hole, shelf
Internal Size(WDH)		400295426mm	4104401330mm	4104401700mm
External Size(WDH)		480460585mm	5956001565mm	5956001965mm
Package Size(WDH)		510532648mm	6306441715mm	6306442015mm
Net Weight		18kg	60kg	77kg
Gross Weight		20.5kg	65kg	82kg
